SpadaConcept Codatronca:
Technical Details:
SpadaConcept Codatronca TS turismo sportivo:
GENERAL
- Vehicle type: Front-mid-engine, RWD 2-door coupe
- Structure: Aluminum Space Frame combined with a magnesium roof structure and engine cradle.
ENGINE
- aluminum block V8 and cylinder head, eight-quart dry-sump lubrication system, titanium valves and connecting rods.
- Type: 7.0 LS7 V-8 with two Italtecnica C38
Rotrex centrifugal superchargers and two intercoolers.
- Displacement (cm3) 7011
- Compression ratio (:1) 11.1
- Power (kW / Horsepower @ rpm): 442 / 600 @ 6300
- Torque (Nm @ rpm) 790 @ 4600
- Fuel feed SFI (sequential fuel injection)
- ValvetrainOHV, 2 valves per cylinder
TRANSMISSION
- Short-Throw 6-speed manual
- Final drive ratio 12/41
- Gear ratio 1st 2.66
- Gear ratio 2nd 1.78
- Gear ratio 3rd 1.30
- Gear ratio 4th 1.00
- Gear ratio 5th 0.83
- Gear ratio 6th 0.71
- Emission class Euro 4
DIMENSIONS
- Weight (kg) 1400
- Wheelbase (mm) 2686
- Track, front/rear (mm) 1607/1580
- Length (mm) 4759
- Width (mm) 1960
- Height (mm) 1240
SUSPENSION, STREERING, BRAKES
- Front and Rear Suspension
Short/long arm (SLA) double wishbone, cast aluminium upper&lower control arms, transverse-mounted composite leaf spring, coaxialspring put on adjustable shock absorber. Adjustable Anterior and posterior anti-roll bar equipped with ball joint
- Steering
Power-assisted, speed-sensitive, magnetic, variable-effort rack-and-pinion with fluid cooler.
- Brakes
Power-assisted disc with ABS, 14-inch front rotors and 13.4-inch rears are vented and cross-drilled, 6-piston front and 4-piston rear calipers.
WHEELS
- Front: 20”; Rear: 20”
PERFORMANCE
- Top speed (km/h) 330
- Acceleration 0-100 km/h (s) 3.2
SpadaConcept Codatronca TSV turismo sportivo veloce:
GENERAL
- Vehicle type: Front-mid-engine, RWD 2-door coupe
- Structure: Aluminum Space Frame combined with a magnesium roof structure and engine cradle.
ENGINE
- aluminum block V8 and cylinder head, eight-quart dry-sump lubrication system, titanium valves and connecting rods.
- Type: 7.0 LS7 V-8 with two Italtecnica C38 Rotrex centrifugal superchargers and two intercoolers.
- Displacement (cm3) 7011
- Compression ratio (:1) 11.1
- Power (kW / Horsepower @ rpm): 515 / 700 @ 6200
- Torque (Nm @ rpm) 950 @ 4200
- Fuel feed SFI (sequential fuel injection)
- ValvetrainOHV, 2 valves per cylinder
TRANSMISSION
- Short-Throw 6-speed manual
- Final drive ratio 12/41
- Gear ratio 1st 2.66
- Gear ratio 2nd 1.78
- Gear ratio 3rd 1.30
- Gear ratio 4th 1.00
- Gear ratio 5th 0.83
- Gear ratio 6th 0.71
- Emission class Euro 4
DIMENSIONS
- Weight (kg) 1380
- Wheelbase (mm) 2686
- Track, front/rear (mm) 1607/1580
- Length (mm) 4759
- Width (mm) 1960
- Height (mm) 1240
SUSPENSION, STREERING, BRAKES
- Front and Rear Suspension
Short/long arm (SLA) double wishbone, cast aluminium upper&lower control arms, transverse-mounted composite leaf spring, coaxialspring put on adjustable shock absorber. Adjustable Anterior and posterior anti-roll bar equipped with ball joint
- Steering
Power-assisted, speed-sensitive, magnetic, variable-effort rack-and-pinion with fluid cooler.
- Brakes
Power-assisted disc with ABS, 14-inch front rotors and 13.4-inch rears are vented and cross-drilled, 6-piston front and 4-piston rear calipers.
WHEELS
Front: 20”; Rear: 20”
PERFORMANCE
Top speed (km/h) 355
Acceleration 0-100 km/h (s) 2.7
SpadaConcept Codatronca TSS turismo super sportivo:
Not yet released.
